Mini Basic PIR Sensor - BS412

SKU: TH0452
₹179.00 Out of Stock
₹211.22 (Incl. GST)
Ships Today - If you order within hrs mins!


Quality
First

Awesome
Support

Secure
Checkout

Nationwide
Shipping

Bulk Order?

Contact sales on WhatsApp and get bulk order discount!
or, mail us on support

Contact Sales

Out of Stock!

We will email you when this item is back in stock. Please enter your email

Overview

Imagine a sensor that can detect movement – whether it's your pet, a person, or even something a bit more unconventional like a zombie (though that's not a guarantee). Well, that's what this PIR sensor is all about! It's a little sensor with a big job.

What sets it apart is its small size. Most PIR sensors are bulkier, but this one is compact, making it perfect for projects where you don't want a big, noticeable sensor. Plus, it's super easy to use – all you need is a power source, a ground connection, and a resistor to tweak the delay time. You can attach it to a breadboard or perfboard without any trouble.

For more information on Mini Basic PIR Sensor - BS412 click here.

Specification

  • Manufacturer Part Number
    BS412
  • Operating Voltage:
    3.3V
  • Digital Output Signal:
    3.3V high/low
  • Adjustable Signal High Time
    2 seconds (0V) to one hour (3.3V) using a resistor divider (refer to the datasheet for recommended resistor values
  • Detection Range:
    Focused to 5 meters with a 120-degree spread, effective from approximately 3 to 8 meters
  • Sensor Window:
    4mm x 3mm
  • Number of Pins:
    4(Pin 1 & 2 Ground, Pin 3 3.3V, and Pin 4 Signal)
  • Focus:
    5mm
  • Angle:
    120 degree

Applications

Mini Basic PIR Sensor - BS412 can be used in many DIY projects such as:

  • Home Secority System
  • Lighting Control
  • Automatic Doors
  • Pet Monitoring
  • Smart Home Automation
