Overview
The TPA3118 PBTL 60W Mono Digital Audio Amplifier is a high-efficiency Class-D amplifier designed for quality audio performance. It operates within a wide supply voltage range of 6V to 24V and delivers up to 60W of output power in mono mode, making it suitable for wide range of audio applications.
Built-in protection features include safeguards against overvoltage, undervoltage, short circuits, DC offset, and thermal faults, ensuring long-term reliability.
With a power efficiency exceeding 90%, the amplifier minimizes heat output and eliminates the need for large heatsinks.
Specification
Technical specification for TPA3118 PBTL 60W Mono Digital Audio Amplifier.
| Chipset | TPA3118D2 |
|---|---|
| Amplifier Type | Class D |
| Operating Voltage | 6 - 24V DC (Exceding 24V may damage the board) |
| Power Output | Up to 60W (at 4Ω, 24V) |
| Output Impedance | 4 - 8 Ω |
| SNR | 102 dB |
| Efficiency | Greater than 90% |
| Weight | 12g |
