PCIe To 2-Ch M.2 Adapter HAT (B) for Raspberry Pi 5

Overview

The PCIe to 2-Channel M.2 Adapter Type B is a high-performance expansion board the Raspberry Pi 5. Designed to enhance storage capabilities, this adapter allows the connection of up to two NVMe M.2 solid-state drives (SSDs) in sizes ranging from 2230 to 2280. It leverages a PCIe x1 Gen2 interface, enabling data transfer rates of up to 5Gbps for significantly improved read and write speeds compared to traditional storage solutions.

This adapter supports booting the Raspberry Pi 5 directly from an NVMe SSD, ensuring faster system startup and seamless operation. Equipped with onboard power monitoring and dual LED indicators, it provides real-time status updates, enhancing system stability and simplifying troubleshooting. Its robust construction features an anti-oxidation immersion gold process, ensuring durability.

What's in the box?

Here's whats included in the box.

1. PCIe TO 2-CH M.2 HAT+ (B) x1
2. 2x20 Pin header x1
3. 16P-Cable-40mm x1
4. Standoff pack x1

Specification

Technical specification for PCIe To 2-Ch M.2 Adapter HAT (B).

Specification	Details
Interface	PCIe x1 Gen2
Supported SSD Sizes	2230, 2242, 2260, 2280
Supported Protocol	NVMe
Compatibility	Designed specifically for Raspberry Pi 5
Data Transfer Rate	Up to 5Gbps
Indicators	Dual LEDs for power and activity status
Additional Features	Onboard EEPROM and power monitoring chip
Dimensions	85 mm x 56.5 mm

SSD Sizes

Compatible SSD Sizes for PCIe To 2-Ch M.2 Adapter HAT (B).
